Autonics Encoder Wheel type ENC-P250 ENC-1-1-N-24

The products you’ve listed are wheel-type incremental rotary encoders from Autonics ENC series, designed to measure the length or speed of continuously moving objects in industrial applications like packaging or textile machinery.

Autonics ENC Series Wheel Encoders

Model	Type	Min. Measuring Unit	Wheel Circumference	Pulses/Revolution	Output Type	Power Supply
ENC-1-1-T-24	Wheel Type Incremental Encoder	1 mm / 1 Pulse	250 mm	250 Pulses	Totem Pole (Push-Pull)	12-24 VDC
ENC-1-1-N-24	Wheel Type Incremental Encoder	1 mm / 1 Pulse	250 mm	250 Pulses	NPN Open Collector	12-24 VDC
ENC-P250	Wheel	N/A	250 mm	N/A	N/A	N/A

ENC-1-1-T-24 vs. ENC-1-1-N-24

ENC-1-1-T-24 that is Totem Pole (Push-Pull) This type can actively for suitable for direct connection to PLCs or counters that accept both PNP and NPN signals.
ENC-1-1-N-24 that is NPN Open Collector This output type is typically used to sink current to ground (drive low) and requires a pull-up resistor if a high signal (voltage) is needed. It’s a common choice for interfaces where the load is connected to the positive supply.
