Schneider Servo Motor LXM32 BMH0701T01A1A
Servo motor BMH Lexium 32 450 W LXM32 Schneider BMH0701T01A1A. The servo motor BMH, Lexium 32, 1.4Nm, 8000rpm, untapped shaft, without brake, IP54, 128bit encoder, straight
Technical specifications and features of this servo motor:
| Feature | Specification |
| Product Type | Synchronous Servo Motor (BMH Series) |
| Compatible Drive | Lexium 32 Servo Drives (e.g., LXM32.U90M2, LXM32.D18M2) |
| Nominal Output Power | Approx. 450 W (when paired with LXM32.U90M2 at 230V, 3A) |
| Continuous Stall Torque | 1.4 N.m (Newton-meters) |
| Peak Stall Torque | 4.0 N.m to 4.2 N.m (depending on the drive) |
| Maximum Mechanical Speed | 8000 rpm |
| Nominal Speed | 4000 rpm (with LXM32.U90M2) |
| Rated Supply Voltage | 240 V (Three Phase) |
| Shaft End | Smooth Shaft (Untapped) |
| Holding Brake | Without Holding Brake |
| Protection Degree | IP54 (Dust-protected, protected against water splashes) |
| Encoder Type | Single-turn SinCos Hiperface |
| Motor Flange Size | 70 mm |
| Electrical Connection | Straight Connectors |
