SIMATIC HMI KP1500 Comfort
The Comfort Panel is touch operation which is 15″ widescreen TFT display PROFINET interface, MPI/PROFIBUS DP interface. There is configurable as of WinCC Comfort V11 SP2, successor: 6AV2124-1QC02-0AX1 configurable from V14 SP1
Technical Specification:
Feature | Specification |
Product Type |
SIMATIC HMI KP1500 Comfort Panel (Key Operation)
|
Display | 15.4-inch Widescreen TFT |
Resolution | 1280 x 800 pixels |
Colors | 16 million colors |
Operation |
Key Operation (Key Panel – “KP” in the name)
|
Function Keys |
36 programmable function keys (with LEDs)
|
Interfaces |
PROFINET (2 ports with integrated switch), MPI/PROFIBUS DP, 2x USB 2.0, 1x RS 485/422, 2x SD card slots
|
Configuration Memory | 24 MB |
Operating System |
Windows Embedded Compact 2013
|
Configuration Software |
Configurable from WinCC Comfort V14 SP1 with HSP (or higher versions in TIA Portal)
|
Supply Voltage | 24 V DC |
Protection Rating | IP65 (front), IP20 (rear) |
Summery:
This panel is part of the Siemens Comfort Panel family, which is known for its high performance, functionality, and ease of integration into the TIA Portal engineering framework. The KP1500 indicates it is a Key Panel meaning the primary method of operation is through the 36 function keys and integrated membrane keypad.
